Overview
The GTR 205 COM Radio delivers integrated communication and audio management for aircraft cockpits. This panel consolidates COM radio functionality with audio routing, enabling pilots to manage multiple communication channels and audio sources from a single interface. Built for reliability in demanding flight environments, it features intuitive controls and clear display of radio frequencies and audio status. The GTR 205X streamlines cockpit workflow by reducing the need for separate radio and audio components, improving efficiency during preflight checks and in-flight operations. Ideal for general aviation and professional flight operations requiring dependable, space-efficient avionics integration.
Specs
GTR 205
Performance:
Communication channels: 760 with 25 kHz spacing; 2280 channels with 8.33 kHz spacing Frequency range: 118.000 to 136.992 MHz Transmit power: 10 watts (16 watts with optional enablement) Input voltage range: 9 to 33 VDC Operating temperature range: -20 to +55 C
Physical:
Dimensions: 1.35”H x 6.25”W (3.43 cm x 15.88 cm) Weight: 2.2 lbs (1 kg) unit only; 2.8 lbs (1.4 kg) with mounting rack and connectors Depth: 10.32 inches (26.21 cm) behind panel, including mounting rack and connectors
Bluetooth
- Bluetooth 5.0 Compliant
- Supported profiles: A2DP and AVRCP (music) and HFP (phone)
- Paired devices stored: 8
- Connections allowed: 1 device
- Supported devices: Phones, tablets, and GDL 51/52 (music). Streaming music from Garmin watches (D2 Delta) is also supported.
- Firmware updates: Free and field loadable by micro-SD card
In The Box
- GTR 205
- Installation rack
- Backplate kit
- Configuration module
- One-time database coupon
