Overview

For Female Standard Density D-Sub Contacts - Shell Size 11

• Series: CPC (Circular Plastic Connector) Series 2
• Connector Type: Plug housing
• Positions: 9
• Shell Size: 11
• Mounting Type: Free-hanging / cable mount
• Coupling Style: Threaded
• Contact Type: Female socket contacts (sold separately)
• Contact Size: Size 20 DF / 20 DM
• Voltage Rating: 250 VDC
• Current Rating: Up to 7.5 A
• Housing Material: Thermoplastic (PA66 Nylon, glass-filled)
• Flammability Rating: UL94 V-0
• Operating Temperature: -55°C to +105°C

Documents

Datasheet
