Overview
The Garmin aera® 760 is a premium portable aviation GPS designed to deliver powerful navigation, situational awareness, and flight planning capabilities in a compact, cockpit-ready device. With its large, sunlight-readable touchscreen and intuitive Garmin interface, the aera 760 functions as both a dedicated in-flight navigator and a full-featured electronic flight bag (EFB).
Features
-
7” Sunlight-Readable Touchscreen – Bright, easy-to-read display optimized for cockpit visibility in all lighting conditions
-
Comprehensive VFR & IFR Navigation – Supports routes, departures, arrivals, and instrument approaches with chart overlay on moving maps
-
All-in-One EFB Capabilities – Includes weather access, charts, PDF viewer, weight & balance tools, and flight planning features
-
Wireless Connectivity – Built-in Wi-Fi® and Bluetooth® enable database updates, weather downloads, and integration with compatible Garmin avionics
-
Enhanced Situational Awareness – Displays ADS-B traffic, weather, terrain, and optional synthetic vision when paired with compatible devices
-
Flexible & Portable Design – No permanent installation required; easily transferable between aircraft and ideal as a backup navigation system
This device is not approved for primary IFR navigation.
Specs
- Physical dimensions: 7.29”W x 4.85”H x 0.91”D (18.5 x 12.3x 2.3 cm)
- Display size: 7" diag (17.8 cm)
- Display resolution, WxH: 480 x 800; portrait and landscape orientation
- Display type: touchscreen WVGA color TFT with white backlight
- Weight: 19.8 oz (561 g)
- Battery: Rechargeable lithium-ion
- Battery life: Up to 4 hours during most daytime conditions, (80% backlight)
- SBAS/WAAS/GLONASS receiver: high-sensitivity with WAAS position accuracy
- Voltage range: 10-35
- Route Data: VFR/IFR
- USB connection: yes (USB-C)
- Expandable memory: yes (microSD™ cards)
