Overview
The Garmin GTR 205XR is a compact remote COM radio designed specifically for experimental and light aircraft. This unit delivers reliable VHF communications with a 10-watt transmit power output, making it ideal for pilots who need dependable air-to-ground connectivity without the complexity of larger avionics systems. Built for experimental aircraft where space and weight are critical considerations, the GTR 205XR integrates seamlessly into existing panel layouts. Its remote-mount design allows flexible installation, keeping the radio unit out of sight while maintaining easy access to controls. The unit features straightforward frequency selection and clear audio reception across the standard aviation COM band. Perfect for bush pilots, experimental builders, and recreational aviators seeking a no-nonsense communication solution that prioritizes reliability and simplicity over advanced features.
Specs
Performance:
Communication channels: 760 with 25 kHz spacing; 2280 channels with 8.33 kHz spacing Frequency range: 118.000 to 136.992 MHz Transmit power: 10 watts Input voltage range: 9 to 33 VDC Operating temperature range: -20 to +55 C
Physical:
Dimensions: 1.35”H x 6.25”W (3.43 cm x 15.88 cm) Weight: 2.0 lbs (1 kg), unit only; 2.6 lbs (1.4 kg), with mounting rack and connectors Depth: 10.32" (26.21 cm) behind panel, including mounting rack and connectors.
In The Box
- GTR 205xR
- Installation rack
- Connector kit
