Overview
The Honeywell 2TL1-10 belongs to the renowned TL Series of environmentally sealed toggle switches qualified to MIL-DTL-3950 military specifications. It is engineered for demanding environments where long operational life and dependable switching are essential.
The 3-position switching arrangement allows selection between multiple active circuits without a center OFF position.
Features
- DPDT circuitry
- 3-position ON-ON-ON operation
- Screw terminal connections
- Panel-mount threaded bushing
- Environment-proof sealing
- Standard nickel-plated lever actuator
- Military-qualified sealed construction
- High-current capability
- Screw-terminal wiring
- Environment-proof sealing
- Shock and vibration resistance
- Long operating life
- UL recognized, CSA certified, and CE approved
Specs
| Specification |
Details |
| Part Number |
2TL1-10 |
| Manufacturer |
Honeywell |
| Series |
MICRO SWITCH™ TL |
| Circuit Type |
DPDT |
| Switch Function |
ON-ON-ON |
| Positions |
3-position |
| Current Rating |
15A AC / 20A DC |
| Voltage Rating |
277VAC / 250VDC |
| Mounting Style |
Panel mount |
| Terminal Type |
Screw terminals |
| Lever Type |
Standard round lever |
| Bushing Thread |
15/32-32 |
| Operating Temperature |
-65°C to +71°C |
| Environmental Protection |
Environment sealed |
| Approvals |
UL, CSA, CE, MIL-DTL-3950 |
Documents
Datasheet
